12mm | 15W/m RGB | IP67 | COB Flexible LED Strip Light

On Sale


$68.00 $75.00
| /

In stock

In stock

Our RGB COB LED strip light uses 840x RGB chips per metre. The use of COB technology means the visible dots are almost eliminated.  This gives the added advantage of not requiring a profile and lens to diffuse the unsightly dots.

COB flexible strip light offers a seamless visual linear light, eliminating any visual dots often found with traditional strip light.  Ideal for installations where the LED strip will not be mounted within profile but seen.

This PCB is made using 3oz copper, this reduces voltage drop, so allows for a continuous 10m length without visible loss of brightness.

This LED strip carries an IP rating of 20, this is an indoor / dry environment LED strip only. Please contact us if you require this strip light with an IP67 protection rating.

Electrical Data
Voltage 24 VDC
Wattage 1m 15 W
Current 1m 0.63 A
LED Data
Package Type COB
Chips LED N/A
Chips 1m 840
Photometric Data
Colour Temperature RGB (Red, Green, Blue)
Colour Rendering Index Ra N/A
Luminous Flux 1m N/A
Luminous Efficacey N/A
Beam Angle 120°
Dimmable 1 ∼ 100% (refer data sheet)
Construction / Protection Data
Substrate Double layer FPCB
Mounting Double sided tape 3M 9080
IP Rating IP67
Operating Temperature -20 ∼ +70 C°
Storage Temperature -20 ∼ +50 C°
Cutting increments 25.0mm
Length 5m
Width 14.0mm
Height 6.0mm
Working Life 70,0000 hrs
